朔州市立式消防泵 批发多级消防泵 卓全定制潜水消防泵
| 材质 | 铸钢 |
|---|---|
| 产地 | 上海 |
| 电动功率 | 37KW |
| 电压 | 380v |
| 工作温度 | 0-45（℃） |
| 进出口径 | 100（mm） |
| 流量 | 30L/S |
| 排出口径 | 100（mm） |
| 驱动方式 | 电动 |
| 吸程 | 2（m） |
| 销售方式 | 网络销售 |
| 性能 | 不阻塞 |
| 扬程 | 80（m） |
| 用途 | 管道泵 |
| 原理 | 叶片泵 |
| 转速 | 2900rpm |
| 执行质量标准 | 国标 |
| 贸易属性 | 促销 |
| 泵轴位置 | 立式 |
| 叶轮数目 | 1 |
| 叶轮结构 | 封闭式叶轮 |
| 叶轮吸入方式 | 单吸式 |
| 发货期限 | 3天 |
| 品牌 | 上海卓全 |
| 型号 | XBD8.0/30G-L |
产品概述 XBD-L型单级单吸消防泵系立式单吸消防泵，供输送不含固体颗粒的清水及物理化学性质类似于水的液体之用。主要用于消防系统增压送水，也可用于厂矿给排水。输送液体的流量范围为5～80L/S，压力范围为0.2～2.25Mpa，配套功率范围为1.5～200KW，口径范围为φ50～φ200mm。
产品用途XBD-L型消防泵主要用于消防系统管道增压送水。也可适用于工业和城市给排水、高层建筑夺压送水、远距离送水、采暖、浴室、锅炉冷暖水循环增压空调制冷系统送水及设备配套等场合。
型号意义
| 型 号 | 流量(L/s) | 压力(MPa) | 效率（%） | 电机功率（KW) | 转速 (r/min) | 汽蚀余量（m) |
| XBD2.1/5-65L | 5 | 0.21 | 68 | 3 | 2900 | 2.5 |
| XBD1.7/5-65L | 5 | 0.17 | 66 | 2.2 | 2900 | 2.5 |
| XBD3.4/5-65L | 5 | 0.34 | 63 | 4 | 2900 | 2.5 |
| XBD2.9/5-65L | 5 | 0.29 | 62 | 4 | 2900 | 2.5 |
| XBD2.5/5-65L | 5 | 0.25 | 58 | 3 | 2900 | 2.5 |
| XBD5.2/5-65L | 5 | 0.52 | 58 | 7.5 | 2900 | 2.5 |
| XBD4.5/5-65L | 5 | 0.45 | 57 | 7.5 | 2900 | 2.5 |
| XBD3.9/5-65L | 5 | 0.39 | 55 | 5.5 | 2900 | 2.5 |
| XBD8.2/5-65L | 5 | 0.82 | 50 | 15 | 2900 | 2.5 |
| XBD7.1/5-65L | 5 | 0.71 | 50 | 11 | 2900 | 2.5 |
| XBD6.0/5-65L | 5 | 0.6 | 49 | 11 | 2900 | 2.5 |
| XBD12.7/5-65L | 5 | 1.27 | 40 | 30 | 2900 | 2.5 |
| XBD11.4/5-65L | 5 | 1.14 | 40 | 22 | 2900 | 2.5 |
| XBD10.2/5-65L | 5 | 1.02 | 39 | 18.5 | 2900 | 2.5 |
| XBD8.5/5-65L | 5 | 0.85 | 38 | 15 | 2900 | 2.5 |
| XBD2.2/10-80L | 10 | 0.22 | 72.5 | 5.5 | 2900 | 3 |
| XBD1.7/10-80L | 10 | 0.17 | 71 | 4 | 2900 | 3 |
| XBD3.2/10-80L | 10 | 0.32 | 71 | 7.5 | 2900 | 3 |
| XBD2.9/10-80L | 10 | 0.29 | 70 | 7.5 | 2900 | 3 |
| XBD2.5/10-80L | 10 | 0.25 | 69 | 5.5 | 2900 | 3 |
| XBD5.3/10-80L | 10 | 0.53 | 67 | 15 | 2900 | 3 |
| XBD4.6/10-80L | 10 | 0.46 | 66 | 11 | 2900 | 3 |
| XBD3.9/10-80L | 10 | 0.39 | 65 | 7.5 | 2900 | 3 |
| XBD8.3/10-80L | 10 | 0.83 | 59 | 22 | 2900 | 3 |
| XBD7.1/10-80L | 10 | 0.71 | 59 | 18.5 | 2900 | 3 |
| XBD6.1/10-80L | 10 | 0.61 | 58 | 15 | 2900 | 3 |
| XBD12.7/10-80L | 10 | 1.27 | 54 | 37 | 2900 | 3 |
| XBD11.2/10-80L | 10 | 1.12 | 54 | 30 | 2900 | 3 |
| XBD10.1/10-80L | 10 | 1.01 | 53 | 30 | 2900 | 3 |
| XBD8.6/10-80L | 10 | 0.86 | 51 | 22 | 2900 | 3 |
| XBD15.5/10-80L | 10 | 1.55 | 66 | 55 | 2900 | 3 |
| XBD14.5/10-80L | 10 | 1.45 | 65 | 45 | 2900 | 3 |
| XBD13.6/10-80L | 10 | 1.36 | 63 | 37 | 2900 | 3 |
| XBD1.9/15-80L | 15 | 0.19 | 72.5 | 5.5 | 2900 | 3 |
| XBD1.4/15-80L | 15 | 0.14 | 71 | 4 | 2900 | 3 |
| XBD3.0/15-80L | 15 | 0.3 | 71 | 7.5 | 2900 | 3 |
| XBD2.6/15-80L | 15 | 0.26 | 70 | 7.5 | 2900 | 3 |
| XBD2.1/15-80L | 15 | 0.21 | 69 | 5.5 | 2900 | 3 |
| XBD4.9/15-80L | 15 | 0.49 | 67 | 15 | 2900 | 3 |
| XBD4.2/15-80L | 15 | 0.42 | 66 | 11 | 2900 | 3 |
| XBD3.5/15-80L | 15 | 0.35 | 65 | 7.5 | 2900 | 3 |
| XBD7.9/15-80L | 15 | 0.79 | 59 | 22 | 2900 | 3 |
| XBD6.6/15-80L | 15 | 0.66 | 59 | 18.5 | 2900 | 3 |
| XBD5.5/15-80L | 15 | 0.55 | 58 | 15 | 2900 | 3 |
| XBD12.4/15-80L | 15 | 1.24 | 54 | 37 | 2900 | 3 |
| XBD10.8/15-80L | 15 | 1.08 | 54 | 30 | 2900 | 3 |
| XBD9.8/15-80L | 15 | 0.98 | 53 | 30 | 2900 | 3 |
| XBD8.3/15-80L | 15 | 0.83 | 51 | 22 | 2900 | 3 |
| XBD14.8/15-80L | 15 | 1.48 | 66 | 55 | 2900 | 3 |
| XBD13.8/15-80L | 15 | 1.38 | 65 | 45 | 2900 | 3 |
| XBD12.7/15-80L | 15 | 1.27 | 63 | 37 | 2900 | 3 |
| XBD2.3/20-100L | 20 | 0.23 | 76 | 11 | 2900 | 4.5 |
| XBD1.8/20-100L | 20 | 0.18 | 74 | 7.5 | 2900 | 4.5 |
| XBD3.6/20-100L | 20 | 0.36 | 76 | 15 | 2900 | 4.5 |
| XBD3.0/20-100L | 20 | 0.3 | 74 | 11 | 2900 | 4.5 |
| XBD2.5/20-100L | 20 | 0.25 | 72 | 11 | 2900 | 4.5 |
| XBD5.3/20-100L | 20 | 0.53 | 74 | 22 | 2900 | 4 |
| XBD4.6/20-100L | 20 | 0.46 | 73 | 18.5 | 2900 | 4 |
| XBD3.9/20-100L | 20 | 0.39 | 71 | 15 | 2900 | 4 |
| XBD8.6/20-100L | 20 | 0.86 | 69 | 37 | 2900 | 4 |
| XBD7.4/20-100L | 20 | 0.74 | 68 | 30 | 2900 | 4 |
| XBD6.2/20-100L | 20 | 0.62 | 66 | 30 | 2900 | 4 |
| XBD13.1/20-100L | 20 | 1.31 | 66 | 75 | 2900 | 4 |
| XBD11.7/20-100L | 20 | 1.17 | 66 | 55 | 2900 | 4 |
| XBD10.4/20-100L | 20 | 1.04 | 65 | 45 | 2900 | 4 |
| XBD8.7/20-100L | 20 | 0.87 | 63 | 37 | 2900 | 4 |
| XBD15.2/20-100L | 20 | 1.52 | 57 | 90 | 2900 | 4 |
| XBD14.4/20-100L | 20 | 1.44 | 75 | 75 | 2900 | 4 |
| XBD13.6/20-100L | 20 | 1.36 | 75 | 55 | 2900 | 4 |
| XBD2.1/25-100L | 25 | 0.21 | 76 | 11 | 2900 | 4.5 |
| XBD1.6/25-100L | 25 | 0.16 | 74 | 7.5 | 2900 | 4.5 |
| XBD3.3/25-100L | 25 | 0.33 | 76 | 15 | 2900 | 4.5 |
| XBD2.8/25-100L | 25 | 0.28 | 74 | 11 | 2900 | 4.5 |
| XBD2.0/25-100L | 25 | 0.2 | 72 | 11 | 2900 | 4.5 |
| XBD5.1/25-100L | 25 | 0.51 | 74 | 22 | 2900 | 4 |
| XBD4.4/25-100L | 25 | 0.44 | 73 | 18.5 | 2900 | 4 |
| XBD3.5/25-100L | 25 | 0.35 | 71 | 15 | 2900 | 4 |
| XBD8.2/25-100L | 25 | 0.82 | 69 | 37 | 2900 | 4 |
| XBD7.0/25-100L | 25 | 0.7 | 68 | 30 | 2900 | 4 |
| XBD5.9/25-100L | 25 | 0.59 | 66 | 30 | 2900 | 4 |
| XBD12.6/25-100L | 25 | 1.26 | 66 | 75 | 2900 | 4 |
| XBD11.3/25-100L | 25 | 1.13 | 66 | 55 | 2900 | 4 |
| XBD10.1/25-100L | 25 | 1.01 | 65 | 45 | 2900 | 4 |
| XBD7.8/25-100L | 25 | 0.78 | 63 | 37 | 2900 | 4 |
| XBD15.0/25-100L | 25 | 1.5 | 57 | 90 | 2900 | 4 |
| XBD13.8/25-100L | 25 | 1.38 | 75 | 75 | 2900 | 4 |
| XBD13.0/25-100L | 25 | 1.3 | 75 | 55 | 2900 | 4 |
| XBD2.0/30-100L | 30 | 0.2 | 76 | 11 | 2900 | 4.5 |
| XBD1.2/30-100L | 30 | 0.12 | 74 | 7.5 | 2900 | 4.5 |
| XBD3.3/30-100L | 30 | 0.33 | 76 | 15 | 2900 | 4.5 |
| XBD2.8/30-100L | 30 | 0.28 | 74 | 11 | 2900 | 4.5 |
| XBD5.1/30-100L | 30 | 0.51 | 74 | 22 | 2900 | 4 |
| XBD4.4/30-100L | 30 | 0.44 | 73 | 18.5 | 2900 | 4 |
| XBD3.5/30-100L | 30 | 0.35 | 71 | 15 | 2900 | 4 |
| XBD8.2/30-100L | 30 | 0.82 | 69 | 37 | 2900 | 4 |
| XBD7.0/30-100L | 30 | 0.7 | 68 | 30 | 2900 | 4 |
| XBD5.9/30-100L | 30 | 0.59 | 66 | 30 | 2900 | 4 |
| XBD12.6/30-100L | 30 | 1.26 | 66 | 75 | 2900 | 4 |
| XBD11.3/30-100L | 30 | 1.13 | 66 | 55 | 2900 | 4 |
| XBD10.1/30-100L | 30 | 1.01 | 65 | 45 | 2900 | 4 |
| XBD7.8/30-100L | 30 | 0.78 | 63 | 37 | 2900 | 4 |
| XBD15.0/30-100L | 30 | 1.5 | 57 | 90 | 2900 | 4 |
| XBD13.8/30-100L | 30 | 1.38 | 75 | 75 | 2900 | 4 |
| XBD13.0/30-100L | 30 | 1.3 | 75 | 55 | 2900 | 4 |
| XBD2.1/40-125L | 40 | 0.21 | 80 | 15 | 2900 | 4 |
| XBD1.6/40-125L | 40 | 0.16 | 77 | 11 | 2900 | 4 |
| XBD3.4/40-125L | 40 | 0.34 | 78 | 22 | 2900 | 4 |
| XBD2.8/40-125L | 40 | 0.28 | 76 | 18.5 | 2900 | 4 |
| XBD2.4/40-125L | 40 | 0.24 | 73 | 15 | 2900 | 4 |
| XBD5.2/40-125L | 40 | 0.52 | 77 | 37 | 2900 | 5.5 |
| XBD4.5/40-125L | 40 | 0.45 | 76 | 30 | 2900 | 5.5 |
| XBD3.6/40-125L | 40 | 0.36 | 75 | 22 | 2900 | 5.5 |
| XBD8.4/40-125L | 40 | 0.84 | 75 | 55 | 2900 | 5 |
| XBD7.2/40-125L | 40 | 0.72 | 74 | 45 | 2900 | 5.5 |
| XBD5.8/40-125L | 40 | 0.58 | 73 | 37 | 2900 | 5.5 |
| XBD12.8/40-125L | 40 | 1.28 | 70 | 90 | 2900 | 5 |
| XBD11.2/40-125L | 40 | 1.12 | 70 | 75 | 2900 | 5 |
| XBD9.8/40-125L | 40 | 0.98 | 69 | 75 | 2900 | 5 |
| XBD8.8/40-125L | 40 | 0.88 | 67 | 55 | 2900 | 5 |
| XBD2.0/45-125L | 45 | 0.2 | 80 | 15 | 2900 | 4 |
| XBD1.5/45-125L | 45 | 0.15 | 77 | 11 | 2900 | 4 |
| XBD3.2/45-125L | 45 | 0.32 | 78 | 22 | 2900 | 4 |
| XBD2.6/45-125L | 45 | 0.26 | 76 | 18.5 | 2900 | 4 |
| XBD2.1/45-125L | 45 | 0.21 | 73 | 15 | 2900 | 4 |
| XBD5.0/45-125L | 45 | 0.5 | 77 | 37 | 2900 | 5.5 |
| XBD4.3/45-125L | 45 | 0.43 | 76 | 30 | 2900 | 5.5 |
| XBD3.4/45-125L | 45 | 0.34 | 75 | 22 | 2900 | 5.5 |
| XBD8.0/45-125L | 45 | 0.8 | 75 | 55 | 2900 | 5 |
| XBD6.9/45-125L | 45 | 0.69 | 74 | 45 | 2900 | 5.5 |
| XBD5.5/45-125L | 45 | 0.55 | 73 | 37 | 2900 | 5.5 |
| XBD12.5/45-125L | 45 | 1.25 | 70 | 90 | 2900 | 5 |
| XBD10.8/45-125L | 45 | 1.08 | 70 | 75 | 2900 | 5 |
| XBD9.6/45-125L | 45 | 0.96 | 69 | 75 | 2900 | 5 |
| XBD8.6/45-125L | 45 | 0.86 | 67 | 55 | 2900 | 5 |
| XBD2.1/50-150L | 50 | 0.21 | 79 | 18.5 | 1450 | 3 |
| XBD1.7/50-150L | 50 | 0.17 | 78 | 15 | 1450 | 3 |
| XBD1.3/50-150L | 50 | 0.13 | 76 | 11 | 1450 | 3 |
| XBD3.3/50-150L | 50 | 0.33 | 78 | 30 | 1450 | 2.5 |
| XBD2.8/50-150L | 50 | 0.28 | 77 | 22 | 1450 | 3.5 |
| XBD2.4/50-150L | 50 | 0.24 | 76 | 18.5 | 1450 | 3.5 |
| XBD5.2/50-150L | 50 | 0.52 | 75 | 45 | 1450 | 3.5 |
| XBD4.4/50-150L | 50 | 0.44 | 74 | 37 | 1450 | 3.5 |
| XBD3.7/50-150L | 50 | 0.37 | 73 | 30 | 1450 | 3.5 |
| XBD3.1/50-150L | 50 | 0.31 | 71 | 22 | 1450 | 3.5 |
| XBD8.2/50-150L | 50 | 0.82 | 76 | 75 | 2900 | 4.5 |
| XBD7.0/50-150L | 50 | 0.7 | 75 | 55 | 2900 | 4.5 |
| XBD5.9/50-150L | 50 | 0.59 | 74 | 45 | 2900 | 4.5 |
| XBD12.8/50-150L | 50 | 1.28 | 73 | 110 | 2900 | 4.5 |
| XBD11.0/50-150L | 50 | 1.1 | 72 | 90 | 2900 | 4.5 |
| XBD9.4/50-150L | 50 | 0.94 | 70 | 75 | 2900 | 4.5 |
| XBD2.0/55-200L | 55 | 0.2 | 79 | 18.5 | 1450 | 3 |
| XBD1.6/55-200L | 55 | 0.16 | 78 | 15 | 1450 | 3 |
| XBD1.2/55-200L | 55 | 0.12 | 76 | 11 | 1450 | 3 |
| XBD3.2/55-200L | 55 | 0.32 | 78 | 30 | 1450 | 3.5 |
| XBD2.7/55-200L | 55 | 0.27 | 77 | 22 | 1450 | 3.5 |
| XBD2.2/55-200L | 55 | 0.22 | 76 | 18.5 | 1450 | 3.5 |
| XBD5.0/55-200L | 55 | 0.5 | 75 | 45 | 1450 | 3.5 |
| XBD4.2/55-200L | 55 | 0.42 | 74 | 37 | 1450 | 3.5 |
| XBD3.5/55-200L | 55 | 0.35 | 73 | 30 | 1450 | 3.5 |
| XBD2.8/55-200L | 55 | 0.28 | 71 | 22 | 1450 | 3.5 |
| XBD2.0/100-200L | 100 | 0.2 | 80 | 30 | 1450 | 4 |
| XBD1.4/100-200L | 100 | 0.14 | 78 | 22 | 1450 | 4 |
| XBD1.0/100-200L | 100 | 0.1 | 75 | 18.5 | 1450 | 4 |
| XBD3.3/100-200L | 100 | 0.33 | 80 | 55 | 1450 | 4 |
| XBD2.8/100-200L | 100 | 0.28 | 79 | 45 | 1450 | 4 |
| XBD2.3/100-200L | 100 | 0.23 | 78 | 37 | 1450 | 4 |
| XBD5.1/100-200L | 100 | 0.51 | 81 | 75 | 1450 | 4 |
| XBD4.4/100-200L | 100 | 0.44 | 80 | 75 | 1450 | 4 |
| XBD3.5/100-200L | 100 | 0.35 | 78 | 55 | 1450 | 5 |
| XBD3.0/100-200L | 100 | 0.3 | 76 | 45 | 1450 | 5 |
| XBD2.0/150-250L | 150 | 0.2 | 82 | 45 | 1450 | 5 |
| XBD1.7/140-250L | 140 | 0.17 | 80 | 37 | 1450 | 5 |
| XBD3.2/140-250L | 140 | 0.32 | 80 | 75 | 1450 | 5.5 |
| XBD2.8/140-250L | 140 | 0.28 | 78 | 55 | 1450 | 5.5 |
| XBD2.1/140-250L | 140 | 0.21 | 74 | 45 | 1450 | 5.5 |
| XBD2.0/140-250L | 140 | 0.2 | 78 | 37 | 1480 | 4.5 |
| XBD5.0/140-250L | 140 | 0.5 | 72 | 90 | 1480 | 4.5 |
| XBD2.0/200-300L | 200 | 0.2 | 83 | 55 | 1450 | 6 |
| XBD2.8/200-300L | 200 | 0.28 | 82 | 75 | 1480 | 5 |
| XBD3.2/200-300L | 200 | 0.32 | 84 | 90 | 1480 | 4.5 |
| XBD4.4/200-300L | 200 | 0.44 | 84 | 132 | 970 | 5 |
| XBD4.2/200-300L | 200 | 0.42 | 78 | 110 | 1480 | 5 |
| XBD1.2/220-350L | 220 | 0.12 | 83 | 37 | 1480 | 4.5 |
| XBD2.0/220-350L | 220 | 0.2 | 82 | 55 | 1480 | 4.5 |
| XBD3.2/220-350L | 220 | 0.32 | 84 | 90 | 1480 | 4.5 |
| XBD5.0/220-350L | 220 | 0.5 | 83 | 160 | 1480 | 4.5 |
