供应空调过滤网 工业空调过滤网 防尘工业空调过滤网
适用对象 | 空气 |
---|---|
性能 | 高效过滤 |
样式 | 板框式 |
用途 | 空气过滤 |
原理 | 重力沉降法 |
质保时间 | 2012-12-10 |
产品用途 | 空气过滤 |
品牌 | 德克贝尔 |
型号 | dirkbiel-003 |
高效无隔板空气过滤器The high-effect non-partition air filter is made of super fine glass fiber paper and other materials and it uses hot-melt adhesive as the partition material to form with the metal frame. It is mainly used for catching dust with the particle size of 0.3um or below. It is the most ideal end filtration system for FFU, clean rooms, work stations and clean sheds. 高效无隔板空气过滤器用超细玻璃纤维纸等制作而成,用热溶胶作分隔物,与金属外框组合而成。主要捕集0.3um以下的尘粒。是FFU、洁净室、工作台、洁净棚等净化系统**的末端过滤装置。(Types)种类:板式、箱式(Materials)材料:aluminum alloy, galvanized sheets, stainless steel sheets, etc.铝合金、镀锌板、不锈钢板等,(protective screens: plastic injection screen and aluminum screen) (保护网:喷塑铝网、铝网)(Filtration materials)过滤材料:super fine glass fiber超细玻璃纤维、PP、PTFE (Filtration effect)过滤效率:99%~99.995%(MPPS、PSL)(Thickness)厚度:50mm、65mm、69mm、70 mm、90mm(Temperature)**高运行温度:80℃±5
Models型号 | Dimensions外形尺寸(mm) | Rated air flow额定风量(m3/h) | Initial resistance初阻力(Pa) | Effect效率(%) |
DHS-5AGN2-305305 | 305×305×50 | 180 | <=220 | H13 |
DHS-5AGN2-6161 | 610×610×50 | 700 | ||
DHS-5AGN2-91561 | 915×610×50 | 1100 | ||
DHS-7AGN2-305305 | 305×305×70 | 250 | ||
DHS-7AGN2-6161 | 610×610×70 | 1500 | ||
DHS-7AGN2-12261 | 1220×610×70 | 2000 | ||
DHS-9AGN2-305305 | 305×305×90 | 150 | 105 | H14 |
DHS-9AGN2-30561 | 305×610×90 | 300 | 100 | |
DHS-9AGN2-6161 | 610×610×90 | 600 | 100 | |
DHS-9AGN2-12261 | 1220×610×90 | 1200 | 100 | |
DHS-9AGN2-915762 | 915×762×90 | 1330 | 100 | |
DHS-9AGN2-915915 | 915×915×90 | 1355 | 100 |
